Environment: Recommended temperature: 18-30ºC Humidity: 10-80%
2. Other similar Models
| EcooSetter Flexo CTP Series Technical Specifications | |||||||
| Model | EcooSetter | EcooSetter | EcooSetter | EcooSetter | EcooSetter | EcooSetter | |
| FL-600E | FL-600S | FL-800E | FL-800S | FL- 1500E | FL-1500S | ||
| Laser Channel | 16CH | 32CH | 16CH | 32CH | 32CH | 64CH | |
| Output Speed | 1.25 m2/h | 2.5 m2/h | 1.25 m2 /h | 2.5 m2 /h | 4.3m2 /h | 8.5 m2/h | |
| Max.Breadth | 26'' x 17''/ 680mm x430mm |
25"x30"/635mmx762mm | 47"×60"/1200mm×1524mm | ||||
| Min. Breadth | 100mmx100mm | ||||||
| Plate Type | Digital relief flexo plate(water-wash) ,digital flexo plate(solvent-wash),steel based digital plate(water/alcohol washable) are applied for EM/SM series | ||||||
| Plate Thickness | 0.7mm - 1.7mm | 0.7mm-2.84mm | 0.9mm-3.94mm | ||||
| Application | Label and trademark | Paper box and soft packaging | |||||
| Resolutions | 4000dpi , optional:3000dpi or 2400dpi | ||||||
| Plate Loading | Manual load and unload | ||||||
| Interface | USB2.0 | ||||||
| Focus Adjust | Dynamic autofocus | ||||||
| Laser Lifetime | >10000h | ||||||
| Device Size (WxDxH)mm |
1087x770x1000 | 1,630×1,170×965 | 2,315×1,370×1,052 | ||||
| Net Weight | 400KG | 800KG | 1200KG | ||||
| Power | Single phase: 220V/50HZ, 60HZ/3KW | Single phase: 200V/50HZ, 60HZ/4.5KW | |||||
| Environment | Recommended temperature: 18-30ºC Hu m i dity: 10%- 80% | ||||||
Our Factory
FAQ:
1. What are your main products ?
Our main products are the Prepress 4up and 8up Online/Offline Thermal CTP , CTCP , VLF CTP and CTCP, Flexo CTP , Processor , Offset Plates ,inks , blankets , postpress Packing equipments and so on.
Our partners in USA,Canada,Mexico,Colombia,Turkey,Hungary,South Africa and so on are very pleased with our Technician Support service and product performance.
You can get the prepress equipment and consumables all in one and no worry about the after-sales service from our company.
2. Where is your factory ?
Our CTP machine factory is located in Hangzhou city , which is about 1.5 hour by train from Shanghai.
You are warmly welcomed to visit our factory!
3. What is your warranty for the CTPs ?
Three years' Laser Head and main spare parts for the CTPs, One year for the Processor.
Lifetime Warranty for the CTP machine combined with the plates.
4. What is the Lead Time?
Usually 10-30 days, and we will try our best to meet your demands.
5. Can you also supply the Workflow and RIP?
Yes, we can provide the Workflow Brain New and RIP Compose V12.
6. What about the Installation and after-sales technician support?
Our engineer can go to help the installation and provide the necessary training. The buyer should take the round air plane tickets and service charge and the local accommodation cost. Any problems or questions,we will available for technical support for 7x24 hours.
